M14 Yellow Chromate 3/8 Inch Concrete Wedge Heavy Hex Bolts Expansion Anchor

  • 1
  • 2

Brand Name : PM

Model Number : M6-M18, 1/4"-1"

Certification : ISO

Place of Origin : CHINA

MOQ : 100PCS

Price : USD 0.001-0.86 PER PCS

Payment Terms : L/C, T/T

Supply Ability : 100 Tons per Month

Delivery Time : 15-25DAYS PER CONTAINER

Packaging Details : 25kgs/carton and 36 cartons on standard export wooden pallets

Material : C1010,C10222

Grade : 4.8, 2

Size : 3/8"

Length : 60-200mm

Surface : Zinc Plated ( Clear/Blue/Yellow/Black )

Thread : UNC

Mark : Manufacturer's ID and Diameter

Product name : Yellow chromate 3/8 inch thread Heavy-duty Concrete Wedge Anchor Bolts

Contact Now

Yellow chromate 3/8 inch thread Heavy-duty Concrete Wedge Anchor Bolts

Wedge Anchors are commonly used on oil rigs, docks, piers, floors, walls, or slabs. They are available in Zinc Plated Steel, Hot Dip Galvanized Coating, and both 304 and 316 Stainless Steel grades. Wedge Anchors are available in 1/4"-20, 3/8"-16, 1/2"-13, 5/8"-11, 3/4"-10, 7/8"-9, and 1"-8 sizes, with the nut and washer included.

SIZE: 1/4" - 1", M6 -M18.

STANDARD: ASME B18.2.6

THREAD: ASME B1.1 , UNC, UNF, CLASS 2A

FINISHED: Plain, Zinc Plated(Clear/Blue/Yellow/Black), Black oxide, Nickel, Dacromet, H.D.G.

Thread Drill hole Length range Thread Drill hole Length range
(mm) (mm) (mm)
M6 6 40-120 1/4" 1/4" ≈45-120
M8 8 50-220 5/16" 5/16" ≈50-145
M10 10 60-250 3/8" 3/8" ≈60-200
M12 12 70-400 1/2" 1/2" ≈70-305
M14 14 80-200 5/8" 5/8" ≈80-305
M16 16 80-300 3/4" 3/4" ≈90-305
M18 18 100-300 1" 1" ≈125-405
M18 20 100-400
M18 24 120-400
